Specifications

• ModelMPE-7501-ACAAW-3B
• ATX VersionATX 12V Ver. 3.1
• PFCActive PFC
• Input Voltage100-240V
• Input Current10-6A
• Input Frequency50-60Hz
• Dimensions (L x W x H)140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
• Fan Size120mm
• Fan BearingHDB
• Efficiency>85% @ Typical Load
• 80 PLUS Rating80 PLUS Bronze
• ErP 2014 Lot 3Yes
• Operating Temperature0-40°C
• Power Good Signal100 – 150 ms
• Hold Up Time>16ms
• MTBF>100,000 Hours
• ProtectionsUVP / OVP / OPP / OTP / SCP
• RegulatorycTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region’s requests.)
• ATX 24 Pin Connectors1
• EPS 8 Pin / 4+4 Pin Connectors2
• SATA Connectors6
• Peripheral 4 Pin Connectors3
• PCI-e 6+2 Pin Connectors4
• Warranty5 Years
• SeriesMWE Bronze Series
• Category500 to 750W
• ModularNon Modular
• 80 Plus EfficiencyBronze
• Form FactorATX
• Watts750W
